| Techical data |
|
| Output voltage at 1000 Hz, 5cm/sec. |
0,2 mV |
| Channel balance at 1 kHz |
< 1,0 dB |
| Channel separation at 1 kHz |
> 25 dB |
| Frequency range at - 3dB |
20-60.000 Hz |
| Frequency response |
20-20.000 Hz +1,5/-0 dB |
| Tracking ability at 315Hz lateral |
>70 µm |
| Compliance, dynamic, lateral |
8 µm/mN |
| Stylus type |
Nude Ortofon Replicant 100 |
| Stylus tip radius |
r/R 5/100 µm |
| Tracking force range |
2,5 - 3,5 g (25 - 35 mN) |
| Tracking force, recommended |
3,0 g |
| Tracking angle |
20° |
| Internal impedance, DC resistance per channel |
6,0 Ohm |
| Recommended load impedance |
>100 Ohm |
| Cartridge body material |
Bakelite |
| Cartridge colour |
Nickel/Black |
| Cartridge weight |
30 g |
|
|
|
|
